MCR Safety Carbon Fiber

BJ238CH

 New

Big Jake® 2
PVC / Nomex Flame Resistant Rain Coat
ANSI Class 3 High Visibility Standard
HRC2 / CAT2, Arc Rating ATPV 11 cal / cm2


Tested in accordance with ASTM F903 – Standard Test Method for Resistance of Materials used in Protective Clothing to Penetration by Liquids
(Test report located below under Specsheet and Downloadable documents section)

Details

Big Jake’s reputation for hard working gloves has now been extended to our garment line. The Big Jake II series is flame resistant and made of PVC / Nomex material, very similar to the original Big Jake Rainwear.  However, the Big Jake 2 is lighter and offers a higher calorie rating than its predecessor.  The BJ238CH 49 Inch coat features a sturdy zipper front with snap over flaps, oversized attached adjustable drawstring hood, stand up collar, adjustable hook and loop wrist closures, and two front patch pockets.  The fluorescent lime background material and two inch silver reflective stripes meet ANSI 107 Class 3 requirements for high visibility protection.  It also meets the ASTM F1891 Standard Specification for Arc and Flame Resistant Rainwear and ASTM F2733 Standard Specification for Flame-Resistant Rainwear for Protection against Flame Hazards.  The BJ238CH achieves an HRC2 / CAT2 ARC rating with an Arc Thermal Performance Value (ATPV) of 11 cal/cm2.  Be seen and be safe in MCR Safety’s Big Jake Hi-Vis FR rainwear.

  • Flame resistant PVC / Nomex 49 Inch raincoat
  • Meets ANSI 107 Class 3 High Visibility Standards
  • Conforms to ASTM F1891 Standard Specification for Arc and Flame Resistant Rainwear
  • Meets ASTM F2733 Standard Specification for Flame-Resistant Rainwear for Protection Against Flame Hazards
  • NFPA 70E with an Arc Thermal Performance Value (ATPV) of 11 cal/cm2
  • Sturdy zipper front with large snap over flaps
  • Two inch Silver FR reflective stripes
  • Two front patch pockets
  • Adjustable / oversized attached hideaway drawstring hood
  • Standup collar for added protection
  • Adjustable hook and loop wrist closures
Size Part No.
M BJ238CHM
L BJ238CHL
XL BJ238CHXL
X2 BJ238CHX2
X3 BJ238CHX3
X4 BJ238CHX4
X5 BJ238CHX5

Class


ANSI/ISEA 107 Class 3 Type R safety apparel requires 1240 in2 of background material and 310 in2 of retro reflective material.  Class 3 can offer greater visibility to the wearer by mandatory placement of background and retro-reflective materials on sleeves and pant legs if present.

Hazard Risk Category


CAT Rating 2 (CAT2) - Minimum Arc Rating of 8.0 cal/cm2

ASTM 1891


Standard Specification for Arc and Flame Resistant Rainwear.

ASTM 2733


Standard Specification for Flame-Resistant Rainwear for Protection Against Flame Hazards.

Technical Specifications

Color
Fluorescent Lime
Flame Resistant
Yes
ASTM 1930 Cert.
Yes
ASTM 1891
Yes
ASTM 2733
Yes
ANSI 107- 2015
Yes
Case Pack
5
Case Dimensions
16.535 x 12.992 x 10.630
Case Weight
18.380 lb.
Weight Each
3.676
